Products
Bespoke Manufacturing
Material Specifications
Key Projects

Display Products by

Gate Valves

Valves

Butterfly Valves

Valves

Globe Valves

Valves

Ball Valves

Valves

Check Valves

Valves

Diaphragm Valves

Valves

Bespoke Manufacturing

GMF is specialized in producing bespoke castings as per the client’s requirements.
A dedicated team is involved in the manufacture of castings for special requests,
focusing robustness and sound quality, ensuring optimum technical and commercial
benefits to our customers.

Material Specifications

We manufacture as per various international standards eg ASTM, Euronorm, DIN and BS.
In order to indicate the various groups of alloys we manufacture, we have specifications
according to ASTM.

Flow Products

Carbon Steel Castings

As per ASTM A216 – Grade WCB & WCC

A 216 - WCB 1.0619 Non corrosive applications for fluids between -30 °C up to +425 °C

A 216 - WCA 1.0619 Non corrosive applications for fluids between -30 °C up to +425 °C

A 216 - WCC 1.0619 Non corrosive applications for fluids between -30 °C up to +425 °C

Low Temperature Carbon Steel

As per ASTM A217 – Grade WC1, WC4,WC5, WC6, WC9, WC11 & C5

A 352 LCB/LLC 1.1156 Low temperature application from -46 °C up to +340 °C

A 352 - LC1 - Low temperature application from -59 °C up to +340 °C

A 352 - LC2 - Low temperature application from -73 °C up to +340 °C

A 217 - LC3 1.5638 Low temperature application from -101 °C up to +340 °C

Low Carbon High Temperature Steel

As per ASTM A217 – Grade WC1, WC4,WC5, WC6, WC9, WC11 & C5

A 217 - WC6 1.7357 With 1.25 % Cr non corrosive application for fluids b/w -30 °C up to +537 °C

A 217 - WC9 - With 2.25 % Cr non corrosive application for fluids b/w -30 °C up to +565 °C

A 217 - C5 1.7363 Mild corrosive application for fluids b/w -30 °C up to +593 °C

A 217 - C12 1.7369 Mild corrosive application for fluids b/w -30 °C up to +640 °C

A 217 - C12 A - Mild corrosive application for fluids b/w -30 °C up to +675 °C

A 217 - CA 15 - Corrosive application up to +704 °C

Nickel Based Steel

A 494 Grade Inconel 625 (CW6 MC) & Inconel 825 (CU5MCuC)

Inconel 625/A494 - CW6MC 2.4856 Extreme resistance to corrosion,hydrogen embrittlement and stress-corrosion cracking

Inconel 825/A494 - CU5MCuC 2.4858 Extreme resistance to corrosion,hydrogen embrittlement and stress-corrosion cracking

Corrosion Resistant Stainless Castings

As per ASTM A351, Grade CF8, CF10, CF8M, CF8C, CF10MC & CN7M.

A 351 - CF8 1.4301 With C 0.08% max corrosive or non corrosive application b/w -260 °C up to +425 °C

A 351 - CF8M 1.4401 With C 0.08% max corrosive or non corrosive application b/w -260 °C up to +425 °C

A 351 - CF3 1.4306 With C 0.03% max corrosive or non corrosive application b/w -260 °C up to +425 °C

A 351 - CF3M 1.4404 With C 0.03% max corrosive or non corrosive application b/w -260 °C up to +425 °C

A 351 - CFC 1.455 Corrosive or non corrosive application b/w -30 °C up to +425 °C

A 487 - CA6NM - 12% chrome for corrosive application up to +425 °C

Duplex & Super Duplex Steel Castings

All grades as per ASTM A 890 (Grades 1A to 6A)

A 890/995 - Grade 4A/CD3MN 1.4462 High corrosive application for fluids b/w -46 °C up to 300 °C

A 890/995 - Grade 5A/CD4MCu 1.4462 High corrosive application for fluids b/w -46 °C up to 300 °C

A 890/995 - Grade 6A/CD4MCuN 1.4501 Chloride stress cracking and high corrosive application for fluids b/w -46 °C up to 300 -425 °C

A 351 - CK3MCuN 1.4547 Chloride stress cracking and high corrosive application for fluids b/w -46 °C up to 300 -425 °C

Engineering & Marine

Heat Resistant Stainless Steel Castings

As per ASTM A297 – Grade HD, HF, HH, HK, and HT

Key Projects

GMF has been a vital part of major projects in the region, supplying valves, pumps and bespoke engineered casting for following client projects.

Saudi Aramco Gulf Metal Foundry Certification

Technip Gulf Metal Foundry Certification

Petrofac Gulf Metal Foundry Certification

Man Diesel Gulf Metal Foundry Certification
